Pro Series ST1050 1/2 HP Cast Iron Submersible Sump Pump w/ Dual Float Switch

Model:

ST1050-DFC1

Write a Review
$234.99
Free Shipping
  Learn More About Free Freight
In-Stock
Ships in 1-2 Business Days
Shipping to60601
Pro Series ST1050 1/2 HP Cast Iron Submersible Sump Pump w/ Dual Float Switch
Pro Series ST1050 1/2 HP Cast Iron Submersible Sump Pump w/ Dual Float Switch
Model: ST1050-DFC1
$234.99
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Sump Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Style

Primary

GPH

5300 Gallons

Switch Type

Dual Vertical Sensor

  • Cast Iron/Cast Aluminum Construction
  • Energy Efficient Permanent Split Capacitor (PSC) Motor
  • Permanent split capacitor (PSC) motor and dual ball bearings
  • Allow for lower amp draw
  • Piggy-back Dual Float Switch with Protective Cage
  • Continuous Duty Rated
  • Stainless Steel Shaft
  • Dual Carbon/Ceramic Seals
  • 10 Cord
  • Will Fit in 10 Diameter Sump Pit
  • Water Cooled (No Oil)
  • 18 Month Warranty (1 year for Continuous Duty)
  • Includes 2" to 1 1/2" reducer

Specifications

ST1050-DFC1
specs product image PID-6565
Base
Min Sump Basin Size
10 Inch
Motor
Voltage
120 Volt
Running Amps
4.8
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
Yes
Starting Amps
9.6
Pump
Housing Material
Cast Iron
Handles Solids
No
Float Type
Dual Vertical Sensor
GPH @ 0 feet
5300
GPH @ 10 feet
4320
Discharge Port Size
2 Inch
Float Cord
10 Feet
Built-in check Valve
No
Float On
Adjustable
Float Off
Timer Based
Manual Override
Yes
Engine
Horsepower
.5 hp
Overview
Weight
28 Pounds
Made in USA
No
Consumer Warranty
1 Year
Product Length
10 Inches
Product Width
6.5 Inches
Product Height
16.25 Inches
UPC
717301121975
Additional Model Numbers

ST1050, ST1050-DFC1
