ProFlo PFTG92352 - 1/3 HP Cast Iron Submersible Sump Package (ABS) w/ Vertical Float Switch
ProFlo PFTG92352 - 1/3 HP Cast Iron Submersible Sump Package (ABS) w/ Vertical Float Switch
+
Share This Product
-
Product Description
-
2Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Style
GPH
3600
Gallons
Switch Type
Style
Primary
GPH
3600 Gallons
Switch Type
Vertical
Features
Features
- PROFLO Pre-Assembled Sump Pump Package
- Everything you need in one box, Makes installing a simple task
- Submersible Sump Pump w/ Vertical Float Switch
- Great for residential and light commercial applications
- 1/3 HP Split Capacitor Motor (1750 RPM)
- Thermally protected, continuous duty design, only draws 7.6A
- Heavy-Duty Cast Iron Housing & Base Construction
- For rapid heat dissipation and extended pump life
- Slim Pump Body w/ SJE Rhombus Vertical Float Switch
- Measure only 8-1/2" wide, great for narrow sump basins
- Side/Bottom Suction w/ Side Discharge (1-1/2")
- Able to pass up to 1/2" solids
- High-Quality Components
- Stainless steel motor shaft & fasteners
- Pump Mounted On Raised Pump Base
- Raises pump off the bottom of the pit to prevent clogging
- Pre-Plumbed w/ Check Valve & ABS Discharge Pipe
- Less complication for a faster installation
- 5-Year Limited Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
7.6
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Pump
Housing Material
Thermoplastic
Solids Handling Size
.5 inch
Float Type
Vertical Float
GPH @ 0 feet
3600
GPH @ 5 feet
3360
GPH @ 10 feet
3000
GPH @ 15 feet
2100
GPH @ 20 feet
900
Discharge Port Size
1-1/2 Inch
Built-in check Valve
Yes
Manual Override
No
Engine
Horsepower
.33 hp
Overview
Weight
28 Pounds
Consumer Warranty
5 Years
Product Length
10 Inches
Product Width
8.5 Inches
Product Height
18 Inches
UPC
781889134962
Style
GPH
3600
Gallons
Switch Type
Style
Primary
GPH
3600 Gallons
Switch Type
Vertical
Features
Features
- PROFLO Pre-Assembled Sump Pump Package
- Everything you need in one box, Makes installing a simple task
- Submersible Sump Pump w/ Vertical Float Switch
- Great for residential and light commercial applications
- 1/3 HP Split Capacitor Motor (1750 RPM)
- Thermally protected, continuous duty design, only draws 7.6A
- Heavy-Duty Cast Iron Housing & Base Construction
- For rapid heat dissipation and extended pump life
- Slim Pump Body w/ SJE Rhombus Vertical Float Switch
- Measure only 8-1/2" wide, great for narrow sump basins
- Side/Bottom Suction w/ Side Discharge (1-1/2")
- Able to pass up to 1/2" solids
- High-Quality Components
- Stainless steel motor shaft & fasteners
- Pump Mounted On Raised Pump Base
- Raises pump off the bottom of the pit to prevent clogging
- Pre-Plumbed w/ Check Valve & ABS Discharge Pipe
- Less complication for a faster installation
- 5-Year Limited Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
7.6
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Pump
Housing Material
Thermoplastic
Solids Handling Size
.5 inch
Float Type
Vertical Float
GPH @ 0 feet
3600
GPH @ 5 feet
3360
GPH @ 10 feet
3000
GPH @ 15 feet
2100
GPH @ 20 feet
900
Discharge Port Size
1-1/2 Inch
Built-in check Valve
Yes
Manual Override
No
Engine
Horsepower
.33 hp
Overview
Weight
28 Pounds
Consumer Warranty
5 Years
Product Length
10 Inches
Product Width
8.5 Inches
Product Height
18 Inches
UPC
781889134962
Product Specs
+−
Specifications
Motor
Voltage
120 Volt
Running Amps
7.6
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Pump
Housing Material
Thermoplastic
Solids Handling Size
.5 inch
Float Type
Vertical Float
GPH @ 0 feet
3600
GPH @ 5 feet
3360
GPH @ 10 feet
3000
GPH @ 15 feet
2100
GPH @ 20 feet
900
Discharge Port Size
1-1/2 Inch
Built-in check Valve
Yes
Manual Override
No
Engine
Horsepower
.33 hp
Overview
Weight
28 Pounds
Consumer Warranty
5 Years
Product Length
10 Inches
Product Width
8.5 Inches
Product Height
18 Inches
UPC
781889134962
