Simer 5020B - 1/3 HP Thermoplastic Pedestal Pump w/ Vertical Float Switch

Name: Simer 5020B - 1/3 HP Thermoplastic Pedestal Pump w/ Vertical Float Switch
Brand: Simer
SKU: 5569
Price: 138.00 USD
Availability: InStock
Rating: 4.80 (5 reviews)

Model:

5020B-04

Write A Review

$138.00

Free Shipping

*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.

Factory-Direct

Ships in 4-7 Business Days

Simer 5020B - 1/3 HP Thermoplastic Pedestal Pump w/ Vertical Float Switch

Model: 5020B-04

$138.00

Accessories

Features

Specifications

Reviews

Product Q&A

How-To Articles

Manuals

Expert Recommended Accessories Selected by Jim, our Expert

Required Accessories 9

These accessories are required to properly setup/install this product.

Optional Accessories 10

Features

Style

Primary

GPH

3480 Gallons

Switch Type

Vertical

Automatic Pedestal Sump Pump
Ideal for sump basins 12" and larger
Durable Thermoplastic Construction
Corrosion and rust-resistant
Energy Efficient 3.5A Motor
Automatic thermal overload protection provides added protection
Fully-Adjustable Vertical Float Switch w/ Metal Switch Arm

California residents see

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

For more information go to: www.p65Warnings.ca.gov

Specifications

5020B-04

General Information

Product Category

Sump Pump

Base

Min Sump Basin Size

12 Inch

Motor

Voltage

120 Volt

Running Amps

3.5

Thermal Protection

Yes

Power Cord Length

6 Feet

Oil Free Motor

Yes

Starting Amps

9.8

Pump

Housing Material

Thermoplastic

Handles Solids

Float Type

Vertical Float

GPH @ 0 feet

3480

GPH @ 5 feet

3000

GPH @ 10 feet

2460

GPH @ 15 feet

1620

Discharge Port Size

1-1/4 Inch

Check Valve Included

Float On

11 Inches

Float Off

5 Inches

Manual Override

Engine

Horsepower

.33 hp

Overview

Product Category

Sump Pump

Weight

15 Pounds

Consumer Warranty

1 Year

UPC

017561910235

Additional Model Numbers

5020B, 5020B-04

Reviews

(5)

Simer 5020B-04 Reviews & Ratings

Product Q&A

(2)

Product Questions Answered by Jim, the Sump Pump Expert

Pedestal vs Non Pedestal sump pump??

Jim Olson

from California

January 03, 2011

Answer

Pedestal sump pumps have become less common and manufacturers are making fewer of them every year.

Here are some advantages of submersible pumps.

If you want a pump that's quiet, less likely to burn out, and can handle a high volume of water, a submersible pump is the style of pump to buy.

Noise Level - The motor and impeller are underwater, these pumps aren’t as loud as a pedestal style pumps, that have their motor exposed above the sump pit.

Running Temperature – By having the motor below water, a submersible pump runs cooler especially during extended periods of use. Pedestal style pumps have no cooling fans, so their motor is cooled by the air around the pump, which is very ineffective during long run times.

Output & Solid Handling- Submersible sump pumps have higher outputs compared to Pedestal style sump pump. They're also able to handle solids that may be present that would otherwise clog a Pedestal pump.

Was this answer helpful?

Yes

What is a Vertical Float Switch?

Jon

from Illinois

December 29, 2010
