Wayne WSSM40V - 1/2 HP Combination Primary and Backup Sump Pump System w/ Advanced Notification

Wayne WSSM40V - 1/2 HP Combination Primary and Backup Sump Pump System w/ Advanced Notification
Model: WSSM40V
Product Discontinued
Sorry, this product is no longer available.
Try This Instead
Discontinued

(as of 07:17 CST - Details) Sales Tax Extra $690.93Visit Site
Discontinued
Sorry, this product is no longer available
Free Shipping
Free Shipping
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • 21
    Reviews
  • 1
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Style
Combo Sumps Pumps
GPH
3900
Gallons
Switch Type
Vertical Float Switch
Style
Combo
GPH
3900 Gallons
Switch Type
Vertical
Features
Features
  • 1/2 HP Combination Primary & Backup Sump Pump System w/ Advanced Notification
  • Assembled in the US with foreign and domestic parts
  • The Hardest Working Pumps, You'll Never Hear™
  • Energy efficient motors & engineered design provide an ultra quiet experience
  • Sump Minder® Advanced Notification System
  • Microprocessor controller monitors & self-tests every 14-days
  • Dialer notification for up to 3 #'s & Port for security system
  • Easily connects to any standard phone line (Required for autodialer)
  • LCD Display
  • Makes it easy to program and check battery status
  • Pre-Assembled and Pre-Plumbed Design For Easier Installation
  • Simple, drop-in installation; Includes (2) Heavy-Duty check valves
  • Epoxy-Coated Steel & Cast Iron Construction (CDU800 - Primary Pump)
  • Rugged, corrosion-resistant design provides long life in sump applications
  • 1/2 HP, Thermally Protected 120V PCS Motor
  • Energy efficient, oil-filled design, for quiet operation and extend motor life
  • Integrated, Guard-Protected Vertical Float Switch w/ Solid Polypropylene Float
  • Prevents switch hang-ups from debris for reliable automatic operation
  • Tested to 1 million cycles*; For performance that lasts (Primary Pump)
  • Unique Top Suction Design w/ Glass Reinforced Polycarbonate Impeller
  • Reduces clogging & prevents air lock occurrences without the need for a "weep hole"
  • Upper/Lower Ball Bearings, Premium John Crane Carbon/Ceramic Shaft Seals
  • Sealed oil-bath engineering for increased lifespan and virtually silent operation
  • High-quality components helps prevent leaks and galvanic corrosion
  • Reinforced Thermoplastic, High Flow 12V Backup Sump Pump (WSM3300 - Backup Pump)
  • Helps extend pump life in harsh sump basin conditions
  • Pumps 3300 gallons-per-hour @ 0' lift (or 2300 GPH @ 10')
  • Adjustable Reed Float Switch
  • Easily mounts at high water level in your sump basin
  • Automatically starts when your existing sump pump fails
  • Audible Alarm For Local Notification
  • Alarms sounds when high water even occurs and pump is running
  • 12V Battery Charger & Thermoplastic Battery Box
  • Smart charging technology for maximum battery efficiency
  • Requires (1) 12V Deep Cycle Battery (SOLD SEPARATELY)
  • Recommended for use with the WAYNE WSB1275, 75 AMP hr maintenance free battery
  • *WAYNE Water Pumps Exceed an Average 1 Million Test Cycles (Primary Pump)
  • 5-Year Limited Warranty
Specifications
Base
Min Sump Basin Size
15 Inch
Motor
Voltage
12 Volt DC/120 Volt AC
Battery Included
No
Thermal Protection
Yes
Power Cord Length
8 Feet
Oil Free Motor
No
Pump
Housing Material
Cast Iron
Handles Solids
No
Float Type
Vertical Float
GPH @ 0 feet
3900
GPH @ 5 feet
3900
GPH @ 10 feet
3150
GPH @ 15 feet
2100
GPH @ 20 feet
600
Discharge Port Size
1-1/2 Inch
Built-in check Valve
Yes
Float On
9 Inches
Float Off
4 Inches
Manual Override
No
Engine
Horsepower
.5 hp
Overview
Weight
35 Pounds
Consumer Warranty
5 Years
UPC
040066215284
Style
Combo Sumps Pumps
GPH
3900
Gallons
Switch Type
Vertical Float Switch
Style
Combo
GPH
3900 Gallons
Switch Type
Vertical
Features
Features
  • 1/2 HP Combination Primary & Backup Sump Pump System w/ Advanced Notification
  • Assembled in the US with foreign and domestic parts
  • The Hardest Working Pumps, You'll Never Hear™
  • Energy efficient motors & engineered design provide an ultra quiet experience
  • Sump Minder® Advanced Notification System
  • Microprocessor controller monitors & self-tests every 14-days
  • Dialer notification for up to 3 #'s & Port for security system
  • Easily connects to any standard phone line (Required for autodialer)
  • LCD Display
  • Makes it easy to program and check battery status
  • Pre-Assembled and Pre-Plumbed Design For Easier Installation
  • Simple, drop-in installation; Includes (2) Heavy-Duty check valves
  • Epoxy-Coated Steel & Cast Iron Construction (CDU800 - Primary Pump)
  • Rugged, corrosion-resistant design provides long life in sump applications
  • 1/2 HP, Thermally Protected 120V PCS Motor
  • Energy efficient, oil-filled design, for quiet operation and extend motor life
  • Integrated, Guard-Protected Vertical Float Switch w/ Solid Polypropylene Float
  • Prevents switch hang-ups from debris for reliable automatic operation
  • Tested to 1 million cycles*; For performance that lasts (Primary Pump)
  • Unique Top Suction Design w/ Glass Reinforced Polycarbonate Impeller
  • Reduces clogging & prevents air lock occurrences without the need for a "weep hole"
  • Upper/Lower Ball Bearings, Premium John Crane Carbon/Ceramic Shaft Seals
  • Sealed oil-bath engineering for increased lifespan and virtually silent operation
  • High-quality components helps prevent leaks and galvanic corrosion
  • Reinforced Thermoplastic, High Flow 12V Backup Sump Pump (WSM3300 - Backup Pump)
  • Helps extend pump life in harsh sump basin conditions
  • Pumps 3300 gallons-per-hour @ 0' lift (or 2300 GPH @ 10')
  • Adjustable Reed Float Switch
  • Easily mounts at high water level in your sump basin
  • Automatically starts when your existing sump pump fails
  • Audible Alarm For Local Notification
  • Alarms sounds when high water even occurs and pump is running
  • 12V Battery Charger & Thermoplastic Battery Box
  • Smart charging technology for maximum battery efficiency
  • Requires (1) 12V Deep Cycle Battery (SOLD SEPARATELY)
  • Recommended for use with the WAYNE WSB1275, 75 AMP hr maintenance free battery
  • *WAYNE Water Pumps Exceed an Average 1 Million Test Cycles (Primary Pump)
  • 5-Year Limited Warranty
Specifications
Base
Min Sump Basin Size
15 Inch
Motor
Voltage
12 Volt DC/120 Volt AC
Battery Included
No
Thermal Protection
Yes
Power Cord Length
8 Feet
Oil Free Motor
No
Pump
Housing Material
Cast Iron
Handles Solids
No
Float Type
Vertical Float
GPH @ 0 feet
3900
GPH @ 5 feet
3900
GPH @ 10 feet
3150
GPH @ 15 feet
2100
GPH @ 20 feet
600
Discharge Port Size
1-1/2 Inch
Built-in check Valve
Yes
Float On
9 Inches
Float Off
4 Inches
Manual Override
No
Engine
Horsepower
.5 hp
Overview
Weight
35 Pounds
Consumer Warranty
5 Years
UPC
040066215284
Product Specs
+
Specifications
Base
Min Sump Basin Size
15 Inch
Motor
Voltage
12 Volt DC/120 Volt AC
Battery Included
No
Thermal Protection
Yes
Power Cord Length
8 Feet
Oil Free Motor
No
Pump
Housing Material
Cast Iron
Handles Solids
No
Float Type
Vertical Float
GPH @ 0 feet
3900
GPH @ 5 feet
3900
GPH @ 10 feet
3150
GPH @ 15 feet
2100
GPH @ 20 feet
600
Discharge Port Size
1-1/2 Inch
Built-in check Valve
Yes
Float On
9 Inches
Float Off
4 Inches
Manual Override
No
Engine
Horsepower
.5 hp
Overview
Weight
35 Pounds
Consumer Warranty
5 Years
UPC
040066215284
Reviews
(21)
+
Wayne WSSM40V Reviews & Ratings
100% of Reviewers Recommend This Product
Product Q&A
(1)
+
Search Product Q&A's Answered by Jim, the Sump Pump Expert
icon-social-fb1
+
does the back up pump run every 14 days? does the back up pump run on both ac and 12 volt dc power? do I need a phone line attached to the battery box? will it dial a cell phone? is there any monthly cost on the advanced notification?
Scott B
from Wisconsin
May 28, 2014
Answer
The Wayne WSSM40V Microprocessor Controller checks for AC power and battery status, then self-tests for float and 12V pump operation every 14 Days. It will only operate on DC power when needed and you do need a land-line for the advanced notification system. Since this notification is through a land based phone system, there is no added monthly charge like you would see on a text notification system.
