Zoeller BE53 - 1/3 HP Cast Iron Submersible Sump Pump w/ Tether Float 230V

Zoeller BE53 - 1/3 HP Cast Iron Submersible Sump Pump w/ Tether Float 230V
Our Price
Compare Prices
Shipping Info
Model: BE53
$258.00

Ships in 2-5 Business Days
Shipping Crate Icon
Free Shipping
Ships in 2-5 Business Days
Free Shipping
Free Shipping
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Style
Primary Sumps Pumps
GPH
2680
Gallons
Switch Type
Piggy-Back Tether Float Switch
Style
Primary
GPH
2680 Gallons
Switch Type
Piggy-Back Tether
Features
Features
  • 230V Non-Automatic Submersible Sump Pump w/ Piggyback Float Switch
  • Ideal for average water removal
  • Piggyback Variable Level Float Switch w/ 15' Cord
  • Fully-adjustable, can accommodate longer pump cycles
  • Cast Iron Switch Case, Motor & Pump Housing
  • Designed for rapid heat dissipation and extended life
  • Engineered Thermoplastic Base
  • Offers years of reliable, trouble-free operation
  • 1/3 HP Thermally Protected Motor (230V)
  • Oil-filled and hermetically sealed to prevent overheating
  • Carbon & Ceramic Shaft Seal
  • Assures maximum protection for extended pump life
  • Clog-Resistant Design
  • No screen to interfere with flowing debris
  • Capable of passing 1/2" diameter solids
  • Industry Leading Quality Control
  • Entire unit is pressure tested after assembly
  • 3-Year Warranty
Specifications
Base
Base Material
Thermoplastic
Min Sump Basin Size
18 Inch
Motor
Voltage
230 Volt
Running Amps
9.7
Thermal Protection
Yes
Power Cord Length
9 Feet
Oil Free Motor
No
Starting Amps
25.9
Pump
Housing Material
Cast Iron
Solids Handling Size
.5 inch
Float Type
Piggy-Back Tether Switch
GPH @ 0 feet
2680
GPH @ 5 feet
2680
GPH @ 10 feet
2040
GPH @ 15 feet
1140
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.33 hp
Overview
Weight
24 Pounds
Made in USA
Yes
Consumer Warranty
3 Years
Dimensions
10.2"L x 7.5"W x 10.2"H
UPC
053514041410
Additional Model Numbers
53-0045, BE53
Style
Primary Sumps Pumps
GPH
2680
Gallons
Switch Type
Piggy-Back Tether Float Switch
Style
Primary
GPH
2680 Gallons
Switch Type
Piggy-Back Tether
Features
Features
  • 230V Non-Automatic Submersible Sump Pump w/ Piggyback Float Switch
  • Ideal for average water removal
  • Piggyback Variable Level Float Switch w/ 15' Cord
  • Fully-adjustable, can accommodate longer pump cycles
  • Cast Iron Switch Case, Motor & Pump Housing
  • Designed for rapid heat dissipation and extended life
  • Engineered Thermoplastic Base
  • Offers years of reliable, trouble-free operation
  • 1/3 HP Thermally Protected Motor (230V)
  • Oil-filled and hermetically sealed to prevent overheating
  • Carbon & Ceramic Shaft Seal
  • Assures maximum protection for extended pump life
  • Clog-Resistant Design
  • No screen to interfere with flowing debris
  • Capable of passing 1/2" diameter solids
  • Industry Leading Quality Control
  • Entire unit is pressure tested after assembly
  • 3-Year Warranty
Specifications
Base
Base Material
Thermoplastic
Min Sump Basin Size
18 Inch
Motor
Voltage
230 Volt
Running Amps
9.7
Thermal Protection
Yes
Power Cord Length
9 Feet
Oil Free Motor
No
Starting Amps
25.9
Pump
Housing Material
Cast Iron
Solids Handling Size
.5 inch
Float Type
Piggy-Back Tether Switch
GPH @ 0 feet
2680
GPH @ 5 feet
2680
GPH @ 10 feet
2040
GPH @ 15 feet
1140
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.33 hp
Overview
Weight
24 Pounds
Made in USA
Yes
Consumer Warranty
3 Years
Dimensions
10.2"L x 7.5"W x 10.2"H
UPC
053514041410
Additional Model Numbers
53-0045, BE53
Product Specs
+
Specifications
Base
Base Material
Thermoplastic
Min Sump Basin Size
18 Inch
Motor
Voltage
230 Volt
Running Amps
9.7
Thermal Protection
Yes
Power Cord Length
9 Feet
Oil Free Motor
No
Starting Amps
25.9
Pump
Housing Material
Cast Iron
Solids Handling Size
.5 inch
Float Type
Piggy-Back Tether Switch
GPH @ 0 feet
2680
GPH @ 5 feet
2680
GPH @ 10 feet
2040
GPH @ 15 feet
1140
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.33 hp
Overview
Weight
24 Pounds
Made in USA
Yes
Consumer Warranty
3 Years
Dimensions
10.2"L x 7.5"W x 10.2"H
UPC
053514041410
Additional Model Numbers
53-0045, BE53
