iON 35ACi Max Deluxe Battery Backup Sump Pump System (3000 GPH @ 10')
Model: MET20339
+
Share This Product
-
Product Description
-
3Reviews
-
1Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Style
GPH
4080
Gallons
Switch Type
Style
Combo
GPH
4080 Gallons
Switch Type
Ion
Features
Features
- Fully Automatic Back-Up Sump Pump System
- iOn 800 Watt Inverter Power Supply
- Converts 12V battery power into standard 120V electricity
- Runs off standard 115V electricity when power is on
- Avoids unnecessary battery drain down
- (2) Heavy Duty 1/3 HP 115V StormPro Sump Pump
- Only draws 4.5 Amps, Extremely efficient, longer run times
- Pumps more water than most 1/2 HP sump pumps
- Ion Genesis Controller - The Brains Of The System
- Ability to adjust pump turn-on levels (1/2" increments)
- Efficiently cycles pumps & minimizes pump turn-on cycles
- Alternates between the two pumps, each cycle
- 2 Digital Level Sensors w/ Discharge Pipe Mounting Brackets
- Eliminates moving parts associated with 98% of switch failures
- Determines pump malfunctions by trending water levels in pit
- 80 dB Audible Alarm and Illuminated LCD Screen
- Hear and see when problems occur
- Dry Contacts For Remote Monitoring
- Optional dialer for remote "Alerts"
- Uses ONE or TWO Deep Cycle Batteries (Not Included)
- Includes larger battery box to enclose 2 batteries and the connectors for 2 battery connection
Specifications
Base
Base Material
Cast Iron
Motor
Voltage
12 Volt DC/120 Volt AC
Battery Included
No
Thermal Protection
Yes
Oil Free Motor
No
Pump
Housing Material
Stainless Steel
Float Type
Ion Sensor
GPH @ 0 feet
4080
GPH @ 5 feet
3660
GPH @ 10 feet
3000
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.33 hp
Overview
Consumer Warranty
3 Years
Style
GPH
4080
Gallons
Switch Type
Style
Combo
GPH
4080 Gallons
Switch Type
Ion
Features
Features
- Fully Automatic Back-Up Sump Pump System
- iOn 800 Watt Inverter Power Supply
- Converts 12V battery power into standard 120V electricity
- Runs off standard 115V electricity when power is on
- Avoids unnecessary battery drain down
- (2) Heavy Duty 1/3 HP 115V StormPro Sump Pump
- Only draws 4.5 Amps, Extremely efficient, longer run times
- Pumps more water than most 1/2 HP sump pumps
- Ion Genesis Controller - The Brains Of The System
- Ability to adjust pump turn-on levels (1/2" increments)
- Efficiently cycles pumps & minimizes pump turn-on cycles
- Alternates between the two pumps, each cycle
- 2 Digital Level Sensors w/ Discharge Pipe Mounting Brackets
- Eliminates moving parts associated with 98% of switch failures
- Determines pump malfunctions by trending water levels in pit
- 80 dB Audible Alarm and Illuminated LCD Screen
- Hear and see when problems occur
- Dry Contacts For Remote Monitoring
- Optional dialer for remote "Alerts"
- Uses ONE or TWO Deep Cycle Batteries (Not Included)
- Includes larger battery box to enclose 2 batteries and the connectors for 2 battery connection
Specifications
Base
Base Material
Cast Iron
Motor
Voltage
12 Volt DC/120 Volt AC
Battery Included
No
Thermal Protection
Yes
Oil Free Motor
No
Pump
Housing Material
Stainless Steel
Float Type
Ion Sensor
GPH @ 0 feet
4080
GPH @ 5 feet
3660
GPH @ 10 feet
3000
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.33 hp
Overview
Consumer Warranty
3 Years
Product Specs
+−
Specifications
Base
Base Material
Cast Iron
Motor
Voltage
12 Volt DC/120 Volt AC
Battery Included
No
Thermal Protection
Yes
Oil Free Motor
No
Pump
Housing Material
Stainless Steel
Float Type
Ion Sensor
GPH @ 0 feet
4080
GPH @ 5 feet
3660
GPH @ 10 feet
3000
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.33 hp
Overview
Consumer Warranty
3 Years
Product Q&A
(1)
+−
Search Product Q&A's
Answered by Jim, the Sump Pump Expert
+−
How long will it run on battery mode compared to a 12 volt pump like basement watchdog uses?
Troy
from Illinois
December 17, 2014
Answer
A standard 12V battery backup system like the Basement Watchdog will run approximately 7 hours continuous and 24-36 hours non-continuous or cycling when using the recommended fully charged battery. That said, these 12V systems will also loose pumping capacity (GPH) as the battery discharges much like a battery powered remote control car that slows as the battery dies, or any other battery powered device. The iON 35ACi System on the other hand is a 12V INVERTER system that converts 12V battery power into standard 120V electricity which means that you get full pumping capacity (GPH) until the batteries are fully discharged. The flow chart on page 8 of the OPERATIONS MANUAL will show you how much time you can expect when using 2 fully charged recommended batteries, from continuous duty up to 10% duty cycles.
If you have additional questions, please let me know.
If you have additional questions, please let me know.
Was this answer helpful?
Yes
0
No
0
