Liberty Pumps ELV290 - 3/4 HP Cast Iron Elevator Sump Pump System w/ OilTector® Control & Alarm

Liberty Pumps ELV290 - 3/4 HP Cast Iron Elevator Sump Pump System w/ OilTector® Control & Alarm
Our Price
Compare Prices
Shipping Info
Model: ELV290
$1,940.40
In-Stock
Ships Monday, Dec 17th
Free Shipping
Holiday Shipping Schedule
Holiday Schedule -
In-Stock
Ships Monday, Dec 17th
Free Shipping
Free Shipping
Expedited Shipping
Expedited Shipping
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+−
Style
Primary Sumps Pumps
GPH
4980
Gallons
Switch Type
Tether Float Switch
Style
Primary
GPH
4980 Gallons
Switch Type
Tether


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • 3/4 HP ELV-Series OilTector® Elevator Sump Pump System
  • For elevator sump pits, transformer vaults and other applications
  • For applications where oil and water must be detected
  • OilTector® System - ASME A17.1 Compliant
  • Activates the pump to remove water from the pit
  • Stops the pump before oil/harmful substances are discharged
  • Heavy-Duty Cast Iron 3/4 HP Sump Pump
  • With 25-foot oil-resistant SJEOOW cord for added protection
  • Easy Installation
  • No field adjustments required, just install & plug-in
  • NEMA 1 Control Panel
  • Separate pump and control circuits for added protection
  • Remote Alarm w/ Audio/Visual Warnings
  • Also provides additional auxiliary (24 VDC) contacts
  • For connection to building automation system or SCADA system
  • Easy To Read Warning Lights
  • Power on, pump run, high water and high oil
  • Includes:
  • 3/4 HP Sump Pump, Level Sensor, Alarm & Control Panel
  • 3-Year Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
10.4
Thermal Protection
Yes
Power Cord Length
25 Feet
Oil Free Motor
No
Starting Amps
24
Pump
Housing Material
Cast Iron
Solids Handling Size
.75 inch
Float Type
Tether Switch
GPH @ 0 feet
4980
GPH @ 5 feet
4620
GPH @ 10 feet
4380
GPH @ 15 feet
3960
GPH @ 20 feet
3480
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Float On
Adjustable
Float Off
Adjustable
Manual Override
Yes
Engine
Horsepower
.75 hp
Overview
Weight
41 Pounds
Consumer Warranty
3 Years
UPC
671812121179
Style
Primary Sumps Pumps
GPH
4980
Gallons
Switch Type
Tether Float Switch
Style
Primary
GPH
4980 Gallons
Switch Type
Tether


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • 3/4 HP ELV-Series OilTector® Elevator Sump Pump System
  • For elevator sump pits, transformer vaults and other applications
  • For applications where oil and water must be detected
  • OilTector® System - ASME A17.1 Compliant
  • Activates the pump to remove water from the pit
  • Stops the pump before oil/harmful substances are discharged
  • Heavy-Duty Cast Iron 3/4 HP Sump Pump
  • With 25-foot oil-resistant SJEOOW cord for added protection
  • Easy Installation
  • No field adjustments required, just install & plug-in
  • NEMA 1 Control Panel
  • Separate pump and control circuits for added protection
  • Remote Alarm w/ Audio/Visual Warnings
  • Also provides additional auxiliary (24 VDC) contacts
  • For connection to building automation system or SCADA system
  • Easy To Read Warning Lights
  • Power on, pump run, high water and high oil
  • Includes:
  • 3/4 HP Sump Pump, Level Sensor, Alarm & Control Panel
  • 3-Year Warranty
Specifications
Motor
Voltage
120 Volt
Running Amps
10.4
Thermal Protection
Yes
Power Cord Length
25 Feet
Oil Free Motor
No
Starting Amps
24
Pump
Housing Material
Cast Iron
Solids Handling Size
.75 inch
Float Type
Tether Switch
GPH @ 0 feet
4980
GPH @ 5 feet
4620
GPH @ 10 feet
4380
GPH @ 15 feet
3960
GPH @ 20 feet
3480
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Float On
Adjustable
Float Off
Adjustable
Manual Override
Yes
Engine
Horsepower
.75 hp
Overview
Weight
41 Pounds
Consumer Warranty
3 Years
UPC
671812121179
Product Specs
+−
Specifications
Motor
Voltage
120 Volt
Running Amps
10.4
Thermal Protection
Yes
Power Cord Length
25 Feet
Oil Free Motor
No
Starting Amps
24
Pump
Housing Material
Cast Iron
Solids Handling Size
.75 inch
Float Type
Tether Switch
GPH @ 0 feet
4980
GPH @ 5 feet
4620
GPH @ 10 feet
4380
GPH @ 15 feet
3960
GPH @ 20 feet
3480
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Float On
Adjustable
Float Off
Adjustable
Manual Override
Yes
Engine
Horsepower
.75 hp
Overview
Weight
41 Pounds
Consumer Warranty
3 Years
UPC
671812121179
