Little Giant 10ECH-CIM - 1/2 HP Cast Iron High Head Effluent/Sump Pump (30' Cord) (Non-Automatic)
Model: 511627
No RatingNo RatingNo RatingNo RatingNo Rating
Number of Reviews(0)
Write a Review
$429.99
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping to60601
Shipping Details
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Style
Effluent Sumps Pumps
GPH
3600
Gallons
Switch Type
None
Style
Effluent
GPH
3600 Gallons
Switch Type
None
Features
Features
  • **NON-AUTOMATIC - Requires Float Switch For Automatic Operation**
  • Designed For High Head Applications
  • Capable of delivering heads up to 60-feet
  • Submersible Cast Iron Sump Pump
  • Continuous duty rated for sump & light effluent applications
  • Polypropylene Base w/ Epoxy Coated Cast Iron Pump Housing
  • Minimizes rust & corrosion to extend overall pump life
  • 1/2 HP PSC Motor w/ Thermal Overload Protection
  • Energy saving design w/ low amp draw (9-Amps full load)
  • Cooler running motor which extends the life of the pump
  • Vortex Style Nylon Impeller
  • Non-clogging design passes up to 1/2" spherical solds
  • No Sheet Metal Parts To Rust Or Corrode
  • Stainless steel intake plate, screws, bolts and handle
  • Nitrile Mechanical Shaft Seal w/ Carbon & Ceramic Faces
  • Assures maximum protection for extended pump life
  • Cold Rolled Steel Shaft w/ Upper/Lower Sintered Sleeve Bearings
  • Minimizes friction while providing smooth & quiet operation
  • 30-Foot Power Cord
  • 2-Year Limited Warrranty
Specifications
Motor
Voltage
120 Volt
Running Amps
9
Thermal Protection
Yes
Oil Free Motor
Yes
Pump
Housing Material
Cast Iron
Solids Handling Size
.75 inch
Float Type
No Switch
GPH @ 0 feet
3600
GPH @ 5 feet
3600
GPH @ 10 feet
3000
GPH @ 20 feet
2700
Discharge Port Size
1-1/2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.5 hp
Overview
Weight
39 Pounds
Consumer Warranty
2 Years
Product Length
8.5 Inches
Product Width
8.4 Inches
Product Height
11.3 Inches
UPC
010121003118
