Pro Series S3100 - 1 HP Cast Iron Submersible Sump Pump w/ Deluxe Controller & Dual Float Switch

Name: Pro Series S3100 - 1 HP Cast Iron Submersible Sump Pump w/ Deluxe Controller & Dual Float Switch
Brand: Pro Series
SKU: 6572
Price: 576.99 USD
Availability: InStock
Rating: 4.17 (6 reviews)

Model:

S3100-DFC2

Write A Review

$576.99

Free Shipping

Only 2 In-Stock

Ships Tuesday, Dec 5th

Shipping to60601

Pro Series S3100 - 1 HP Cast Iron Submersible Sump Pump w/ Deluxe Controller & Dual Float Switch

Model: S3100-DFC2

$576.99

Accessories

Features

Specifications

Reviews

Product Q&A

How-To Articles

Manuals

Expert Recommended Accessories Selected by Jim, our Expert

Required Accessories 9

These accessories are required to properly setup/install this product.

Optional Accessories 10

Features

Style

Primary

GPH

5940 Gallons

Switch Type

Dual Vertical Sensor

Cast Iron / Stainless Steel Construction
Energy Efficient Permanent Split Capacitor (PSC) Motor
Piggy-back Dual Float Switch with Cage
Deluxe Controller
Monitors power conditions and sounds an alarm when:
AC power is out or circuit breaker is tripped
Float has been raised for more than 10 minutes
9-volt battery needs replacement
Continuous Duty Rated
Stainless Steel Shaft
Dual Carbon/Ceramic Seals
20' Pump Cord
Output terminals for Connection to a Security System or Auto-dial
Water Cooled (no oil)
3-year warranty (1 year for continuous duty)

Specifications

S3100-DFC2

General Information

Product Category

Sump Pump

Base

Base Material

Cast Iron

Motor

Voltage

120 Volt

Running Amps

11.5

Thermal Protection

Yes

Power Cord Length

20 Feet

Oil Free Motor

Yes

Nominal Voltage

120 Volt

Starting Amps

Pump

Housing Material

Cast Iron

Impeller Material

Cast Iron

Total Head Lift

52 Feet

Float Type

Dual Vertical Sensor

GPH @ 0 feet

5940

GPH @ 10 feet

5520

Discharge Port Size

2 Inch

Float Cord

10 Feet

Check Valve Included

Manual Override

Yes

Engine

Horsepower

1 hp

Overview

Product Category

Sump Pump

Weight

46 Pounds

Consumer Warranty

3 Years

Commercial Warranty

1 Year

Product Length

11 Inches

Product Width

7.7 Inches

Product Height

18 Inches

UPC

717301121678

Additional Model Numbers

S3100, S3100-DFC2

Reviews

(6)

Pro Series S3100-DFC2 Reviews & Ratings

Product Q&A

(4)

Product Questions Answered by Jim, the Sump Pump Expert

what is the difference between a sewer injector pump and a sump pump? can i use the same pump for each activity? thanks

Russell Abrams

from New York

October 29, 2012

Answer

Sewer ejector pumps will generally provide a higher pumping capacity and the ability to pump up to 2 inch solids whereas most sump pumps max out at about 5000-6000GPH and MAY only handle small solids up to 1/2 of an inch. Please keep in mind however, that your sewage ejector pumps also require a 2 inch discharge pipe to be installed to achieve the above stated specs. Use of a sewage ejector pump in a sump application is fairly common for high pumping capacity applications as long as the discharge is installed correctly. You do NOT want to use a sump pump in a sewage application however!!

Was this answer helpful?

Yes

Can you set the on depth and off depth on the dual sensor switch, like on at 1/2 ft and off at 3"?

Don F

from Minnesota

July 15, 2012

Answer

The dual float switch actually works on a timer once the float is raised a 1/4" from it's original position. Once the float is raised, it will activate the pump. Once the float is back in it's original position, the pump will operate for an additional 10 seconds and stop until the pump is activated again. You can set the level at which you want the pump to activate however.

Per the instructions for the Pro Series S3100:

Position the float switch to a level where the bottom of the float cage is no lower than 3 above the bottom of the pump and no higher than 1 below the top of the pit. To avoid debris pouring into the float, it should be positioned on the side of the discharge pipe opposite the drain tile. Note: It is important to mount the float below the drain tile that empties into the pit. Mounting it above the drain tile would allow water to fill the drain tile before the pump is activated to pump out the water.

Was this answer helpful?

Yes

for my cabin i need a sump pump that will have a lift of 40 ft and less than 10 gaper minute. the distance is 42 feet. what size of discharge pipe will be needed and also a check valve thank you

Dave Higgins

from Washington

August 06, 2011

What is a dual vertical sensor switch?

Mitch Miller

from Montana

June 11, 2011

Answer

The dual float switch contains two large floating rings enclosed within a protective cage. Water will lift the bottom float by a 1⁄4, which will activate the pump. If for any reason the lower float does not activate the pump, the water will rise and
activate the second switch. As the pump evacuates the water from the pit the floats will drop. The pump will run for an additional 10 seconds to extend the cycle after the lower float drops.
Note: When mounting the float switch, position the
bottom of the cage at the height you want the pump to activate.

Was this answer helpful?

Yes
