iON 1/3 HP Cast Iron Stainless Steel Sump Pump (Non-Automatic) HP20180
Model: HP20180
+
Share This Product
-
Product Description
-
9Reviews
-
4Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Style
GPH
4080
Gallons
Switch Type
None
Style
Primary
GPH
4080 Gallons
Switch Type
None
Features
Features
- Powerful & Efficient Submersible Pump
- Ideal for heavy-duty sump applications
- Cast Iron Stainless Steel Construction
- Ensures years of reliable operation
- Thermally Protected Motor
- reduces overheating
- Stainless Steel Screened Intake
- Prevents debris from entering the pump
- Poly Resin Top Cap and Handle
- Made for easy installation and maintenance
Specifications
Base
Base Material
Cast Iron
Min Sump Basin Size
10 Inch
Motor
Voltage
120 Volt
Running Amps
4.5
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Starting Amps
12
Pump
Housing Material
Stainless Steel
Impeller Material
Plastic
Solids Handling Size
.5 inch
Handles Solids
Yes
Float Type
No Switch
GPH @ 0 feet
4080
GPH @ 5 feet
3660
GPH @ 10 feet
3000
GPH @ 15 feet
2400
GPH @ 20 feet
1260
Discharge Port Size
1-1/2 Inch
Submersible
Yes
Engine
Horsepower
.33 hp
Overview
Weight
21 Pounds
Consumer Warranty
3 Years
Product Length
7.75 Inches
Product Width
5.5 Inches
Product Height
12.5 Inches
UPC
6482605856314
Additional Model Numbers
BA-33, HP20180
Style
GPH
4080
Gallons
Switch Type
None
Style
Primary
GPH
4080 Gallons
Switch Type
None
Features
Features
- Powerful & Efficient Submersible Pump
- Ideal for heavy-duty sump applications
- Cast Iron Stainless Steel Construction
- Ensures years of reliable operation
- Thermally Protected Motor
- reduces overheating
- Stainless Steel Screened Intake
- Prevents debris from entering the pump
- Poly Resin Top Cap and Handle
- Made for easy installation and maintenance
Specifications
Base
Base Material
Cast Iron
Min Sump Basin Size
10 Inch
Motor
Voltage
120 Volt
Running Amps
4.5
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Starting Amps
12
Pump
Housing Material
Stainless Steel
Impeller Material
Plastic
Solids Handling Size
.5 inch
Handles Solids
Yes
Float Type
No Switch
GPH @ 0 feet
4080
GPH @ 5 feet
3660
GPH @ 10 feet
3000
GPH @ 15 feet
2400
GPH @ 20 feet
1260
Discharge Port Size
1-1/2 Inch
Submersible
Yes
Engine
Horsepower
.33 hp
Overview
Weight
21 Pounds
Consumer Warranty
3 Years
Product Length
7.75 Inches
Product Width
5.5 Inches
Product Height
12.5 Inches
UPC
6482605856314
Additional Model Numbers
BA-33, HP20180
Product Specs
+−
Specifications
Base
Base Material
Cast Iron
Min Sump Basin Size
10 Inch
Motor
Voltage
120 Volt
Running Amps
4.5
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Starting Amps
12
Pump
Housing Material
Stainless Steel
Impeller Material
Plastic
Solids Handling Size
.5 inch
Handles Solids
Yes
Float Type
No Switch
GPH @ 0 feet
4080
GPH @ 5 feet
3660
GPH @ 10 feet
3000
GPH @ 15 feet
2400
GPH @ 20 feet
1260
Discharge Port Size
1-1/2 Inch
Submersible
Yes
Engine
Horsepower
.33 hp
Overview
Weight
21 Pounds
Consumer Warranty
3 Years
Product Length
7.75 Inches
Product Width
5.5 Inches
Product Height
12.5 Inches
UPC
6482605856314
Additional Model Numbers
BA-33, HP20180
Product Q&A
(4)
+−
Search Product Q&A's
Answered by Jim, the Sump Pump Expert
+−
What is the discharge pipe diameter and does it plug directly into an outlet?
Cory
from Florida
July 24, 2017
Answer
Hello Cory. The iON BA-33 1/3HP pump requires a 1-1/2" discharge pipe, preferably PVC SCH40 and comes with a 10 foot power cord and plug, ready to plug into a dedicated 120V outlet.
Was this answer helpful?
Yes
1
No
0
+−
Can the StormPro 1/2 HP Cast Iron Stainless Steel Sump Pump be used with back-up battery or it must be plug in to an electrical outlet.
JAMES P
from New York
September 24, 2012
Answer
The StormPro model BA-50M, 1/2HP sump pump is designed to be operated on 120 volts AC. There currently is no battery capable of powering a 120 volt primary sump pump. The only possible options would be an AUXILARY POWER SYSTEM which will operate up to a 1/2HP pump for up to 10-12 hours continuous or 24-36 hours non-continuous, a complete BATTERY BACKUP SYSTEM or looking into the possibility of installing a STANDBY GENERATOR.
Was this answer helpful?
Yes
1
No
0
+−
What kind of warranty do you have on your pumps?
John
from Pennsylvania
July 03, 2012
Answer
Pump warranties vary from 1 year to 5 years depending on the pump and the manufacturer. That being said, all pumps should last a good 5-7 years or more providing they are installed properly.
Was this answer helpful?
Yes
1
No
1
+−
I would like to buy the storm pro 1/3 hp pump but would like level switch to control over a longer span (deep pit with higher flow rates at times) want to minimize cycles. Is there a different longer switch rod that can replace the stock version.
Barry
from Minnesota
May 08, 2012
Answer
Unfortunately not! Your only options would be the Pro Series Ultimate Sensor Pump Controller System, model USC3 or the Superior Pump Wide Angle Tether Float Switch w/ Piggyback Plug, model 92005. The Pro Series switch can be adjusted to pump for 5 - 45 seconds once the water level drops below the sensor and the Superior tether float has an adjustable pumping range of 7” to 36”.
Was this answer helpful?
Yes
0
No
0
