iON 3/4 HP Cast Iron Stainless Steel Sump Pump w/ Digital Level Control HP20159
iON 3/4 HP Cast Iron Stainless Steel Sump Pump w/ Digital Level Control HP20159
+
Share This Product
-
Product Description
-
3Reviews
-
3Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Style
GPH
5100
Gallons
Switch Type
Style
Primary
GPH
5100 Gallons
Switch Type
Ion
Features
Features
- Powerful & Efficient Submersible Pump
- Ideal for heavy-duty sump applications
- Cast Iron Stainless Steel Construction
- Ensures years of reliable operation
- Thermally Protected Motor
- reduces overheating
- Cast Iron Impeller
- Offers reliable pumping
- Stainless Steel Screened Intake
- Prevents debris from entering the pump
- Poly Resin Top Cap and Handle
- Made for easy installation and maintenance
- Ion Digital Level Control w/ 6" Range
- Eliminates moving parts associated with 98% of switch failures
- Attaches to discharge pipe for customized installation
- *Note - (IN-SPB1-1) Required For Mounting Sensor On Pipe
- 20' Cord
- Min sump pump basin size 18" X 24"
Specifications
Motor
Voltage
120 Volt
Running Amps
7.7
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
No
Starting Amps
20.4
Pump
Housing Material
Stainless Steel
Solids Handling Size
0.5 inch
Float Type
Ion Sensor
GPH @ 0 feet
5100
GPH @ 5 feet
4800
GPH @ 10 feet
4440
GPH @ 15 feet
4080
GPH @ 20 feet
3600
Discharge Port Size
2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.75 hp
Overview
Weight
31 Pounds
Consumer Warranty
3 Years
Product Length
8.75 Inches
Product Width
5.75 Inches
Product Height
14.5 Inches
UPC
6482605855942
Style
GPH
5100
Gallons
Switch Type
Style
Primary
GPH
5100 Gallons
Switch Type
Ion
Features
Features
- Powerful & Efficient Submersible Pump
- Ideal for heavy-duty sump applications
- Cast Iron Stainless Steel Construction
- Ensures years of reliable operation
- Thermally Protected Motor
- reduces overheating
- Cast Iron Impeller
- Offers reliable pumping
- Stainless Steel Screened Intake
- Prevents debris from entering the pump
- Poly Resin Top Cap and Handle
- Made for easy installation and maintenance
- Ion Digital Level Control w/ 6" Range
- Eliminates moving parts associated with 98% of switch failures
- Attaches to discharge pipe for customized installation
- *Note - (IN-SPB1-1) Required For Mounting Sensor On Pipe
- 20' Cord
- Min sump pump basin size 18" X 24"
Specifications
Motor
Voltage
120 Volt
Running Amps
7.7
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
No
Starting Amps
20.4
Pump
Housing Material
Stainless Steel
Solids Handling Size
0.5 inch
Float Type
Ion Sensor
GPH @ 0 feet
5100
GPH @ 5 feet
4800
GPH @ 10 feet
4440
GPH @ 15 feet
4080
GPH @ 20 feet
3600
Discharge Port Size
2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.75 hp
Overview
Weight
31 Pounds
Consumer Warranty
3 Years
Product Length
8.75 Inches
Product Width
5.75 Inches
Product Height
14.5 Inches
UPC
6482605855942
Product Specs
+−
Specifications
Motor
Voltage
120 Volt
Running Amps
7.7
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
No
Starting Amps
20.4
Pump
Housing Material
Stainless Steel
Solids Handling Size
0.5 inch
Float Type
Ion Sensor
GPH @ 0 feet
5100
GPH @ 5 feet
4800
GPH @ 10 feet
4440
GPH @ 15 feet
4080
GPH @ 20 feet
3600
Discharge Port Size
2 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
.75 hp
Overview
Weight
31 Pounds
Consumer Warranty
3 Years
Product Length
8.75 Inches
Product Width
5.75 Inches
Product Height
14.5 Inches
UPC
6482605855942
Product Q&A
(3)
+−
Search Product Q&A's
Answered by Jim, the Sump Pump Expert
+−
Does a weep hole need to be made with this unit tp prevent air lock.
Dan G
from New Jersey
April 03, 2012
Answer
A weep hole should be drilled in the discharge pipe when using any bottom/side discharge sump pumps such as the StormPro. The only pumps that we offer that do not require the weep hole would be the BASEMENT WATCHDOG sump pumps with their top discharge design. These pump actually have an air relief valve at the top of the pump.
+−
Is the Storm Pro Ba33m 1/3 HP UL inspected?
Gregory Speicher
from Pennsylvania
January 28, 2012
Answer
No they are not, but they do carry the CSA certification.
CSA International (Canadian Standards Association), a member of the CSA Group, is a provider of product testing and certification services for electrical, mechanical, plumbing, gas and a variety of other products. Recognized in the U.S., Canada and around the world, CSA’s marks appear on billions of products worldwide.
CSA International certification marks indicate that a product, process or service has been tested to a Canadian or U.S. standard and it meets the requirements of an applicable CSA standard or another recognized document used as a basis for certification.
CSA International (Canadian Standards Association), a member of the CSA Group, is a provider of product testing and certification services for electrical, mechanical, plumbing, gas and a variety of other products. Recognized in the U.S., Canada and around the world, CSA’s marks appear on billions of products worldwide.
CSA International certification marks indicate that a product, process or service has been tested to a Canadian or U.S. standard and it meets the requirements of an applicable CSA standard or another recognized document used as a basis for certification.
+−
How does the sump pump connect to the independent float switch, Does the pump plug into the switch and the switch plugs into the power?
Mark
from New Jersey
February 09, 2011
Answer
Yes, most external float switches utilize this design. It's consider a "Piggyback" style plug. Very similar to how sets of Christmas lights connect to each other.
