iON Products JSPIII+P20233H
iON Products JSPIII+P20233H
Hover to zoom
1 Of 5

Ion JSPIII Preassembled Sump and Battery Backup System (4080 GPH @ 10') & Battery

Model:

JSPIII+P20233H

Write a Review
$1,126.00
Free Shipping
  Learn More About Free Freight
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.

Ion JSPIII Preassembled Sump and Battery Backup System (4080 GPH @ 10') & Battery
Ion JSPIII Preassembled Sump and Battery Backup System (4080 GPH @ 10') & Battery
Model: JSPIII+P20233H
$1,126.00
Accessories
Features
Specifications
Reviews
Product Q&A
How-To Articles
Manuals
Share

Recommended Accessories

Sump Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Style

Combo

GPH

4080 Gallons

Switch Type

Ion

  • Ion JSP-III Primary & Battery Backup Sump Pump System
  • Comes fully assembled & ready to Install
  • 1/3 HP High-Volume Primary Pump w/ iON Digital Level Control
  • Cast iron & engineered thermoplastic to extend pump life
  • Thermally Protected Oil-Filled Motor
  • Highly efficient & uses half the power of most 1/3 HP pumps
  • Piggyback Ion Digital Level Control Primary Switch
  • First of a kind solid-state sensing technology w/ no moving parts
  • 2100DC Battery Powered 12V Heavy-Duty Sump Pump
  • Provides up to 2100 GPH @ 10' Lift
  • Backup Pump Base
  • Minimizes clogging from debris by keep pump off the basin bottom
  • 8-Amp 5-Stage High Output Processor Based Charger Unit
  • Switches to DC mode automatically when power is out
  • Added Features
  • Heavy-duty adj. vertical float switch mounts on discharge pipe
  • Audible Alarms/Idicator Lights for added protection
  • 1-1/2" Sch. 40 PVC Pup & Includes All Valves
  • Check valve on each pump and combo valve on main discharge
  • INCLUDES (1) Deep Cycle Maintenance-Free AGM Battery (P20233)

Specifications

JSPIII+P20233H
specs product image PID-14999
Base
Min Sump Basin Size
18 Inch
Motor
Voltage
12 Volt DC/120 Volt AC
Running Amps
4.5
Battery Included
Yes
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Pump
Housing Material
Stainless Steel
Solids Handling Size
.5 inch
Float Type
Ion Sensor
GPH @ 0 feet
4080
GPH @ 5 feet
3660
GPH @ 10 feet
3000
GPH @ 15 feet
2400
GPH @ 20 feet
1260
Discharge Port Size
1-1/2 Inch
Built-in check Valve
Yes
Manual Override
Yes
Engine
Horsepower
.33 hp
Overview
Weight
124 Pounds
Consumer Warranty
3 Years
