Goulds WS_B Series - 1/3 HP Cast Iron Sewage Pump (Non-Automatic)

Model:

WS0311B

Write a Review
$692.30
Free Shipping
  Learn More About Free Freight
Backordered
Estimated Availability September 29, 2021
Shipping to60601

Goulds WS_B Series - 1/3 HP Cast Iron Sewage Pump (Non-Automatic)
Goulds WS_B Series - 1/3 HP Cast Iron Sewage Pump (Non-Automatic)
Model: WS0311B
$692.30
Features
Specifications
Reviews
Product Q&A
Accessories
How-To Articles
Manuals
Share

Features

Style

Sewage Pump

GPH

4800 Gallons

Switch Type

None

  • ***NON-AUTOMATIC - Requires Float Switch or Controller***
  • Goulds WS_B Series Cast Iron Submersible Sewage Pump
  • Designed for light sewage removal in residential applications
  • Heavy-Duty Cast Iron Housing & Volute
  • Robust design provides maximum efficiency
  • Can be installed on A10-20 guide rail or base elbow rail systems
  • 1/3 HP, Capacitor Start Motor
  • Oil-filled and thermally protected w/ auto reset
  • Fully-submerged design provides efficient heat transfer
  • Cast Iron, Semi-Open Impeller
  • Dynamically balanced, non-clog design w/ pump out vanes
  • Easily handles solids up to 2"
  • Silicon Carbide Mechanical Seal
  • Provides superior abrasion resistance
  • Stainless Steel Shaft & Upper / Lower Ball Bearings
  • Helps extend the lifespan of the pump
  • Designed for Continuous Operation
  • Can be operated continuously without damage when fully submerged
  • Capable of running dry without damage to components
  • 2" NPT (Female) Discharge
  • Will replace most pumps without any plumbing changes
  • 20-Foot Power Cord w/ Plug
  • Severe duty rated, oil and water resistant
  • 1-Year Limited Warranty

Specifications

WS0311B
specs product image PID-96911
Base
Base Material
Cast Iron
Motor
Voltage
120 Volt
Running Amps
10.7
Thermal Protection
Yes
Power Cord Length
20 Feet
Oil Free Motor
No
Pump
Mechanical Seal Material
Silicon Carbide
Housing Material
Cast Iron
Impeller Material
Cast Iron
Solids Handling Size
2 inch
Handles Solids
Yes
Float Type
No Switch
GPH @ 0 feet
4800
GPH @ 5 feet
4800
GPH @ 10 feet
4800
GPH @ 15 feet
2160
Discharge Port Size
2 Inch
Built-in check Valve
No
Submersible
Yes
Engine
Horsepower
.33 hp
Overview
Weight
74 Pounds
Made in USA
Yes
Consumer Warranty
1 Year
Product Length
12 Inches
Product Width
8.25 Inches
Product Height
19 Inches
UPC
697666009241
