Liberty Pumps LE51AV - 1/2 HP Cast Iron Sewage Pump (2") w/ Vertical Float Switch
Model: LE51AV
No RatingNo RatingNo RatingNo RatingNo Rating
Number of Reviews(0)
Write a Review
$383.25
Free Shipping
  Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
In-Stock
Ships in 1-2 Business Days
Shipping to60601
Shipping Details
*We currently CANNOT ship this product to Canada or any destination outside of the United States

Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Style
Sewage Pumps
GPH
9600
Gallons
Switch Type
Vertical Float Switch
Style
Sewage Pump
GPH
9600 Gallons
Switch Type
Vertical
Features
Features
  • Automatic Submersible Cast Iron Sewage Pump
  • A workhorse for residential & light commercial sewage apps.
  • Heavy-Duty Epoxy Powder Coated Cast Iron Construction
  • Designed to provide years of reliable performance
  • Pump-Mounted Vertical Float Switch
  • Provides automatic or manual operation via piggyback plug
  • Rugged & Thermally Protected 1/2 HP Motor
  • Hermetically sealed, permanently lubricated design
  • Engineered 2-Vane Semi-Open HYTREL Polymer Impeller
  • Corrosion-resistant design, passes spherical solids up to 2"
  • High Capacity 2" Discharge
  • Will replace most sewage pumps without any plumbing changes
  • Quick-Disconnect 10' Power Cord
  • Allows for easy replacement of cord without breaking motor seals
  • Stainless Steel Rotor Shaft w/ Unitized Ceramic Carbon Seal
  • With permanently lubricated bearings for extended pump life
  • Non-Corrosive Stainless Steel & Brass Fasteners
  • Increases the lifespan of the pump even in the harshest systems
  • 3-Year Limited Warranty
Specifications
Base
Min Sump Basin Size
14 Inch
Motor
Voltage
120 Volt
Running Amps
12
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Starting Amps
22.5
Pump
Housing Material
Cast Iron
Solids Handling Size
2 inch
Float Type
Vertical Float
GPH @ 0 feet
9600
GPH @ 5 feet
8400
GPH @ 10 feet
6720
GPH @ 15 feet
5400
GPH @ 20 feet
3300
Discharge Port Size
2 Inch
Built-in check Valve
No
Manual Override
Yes
Max Head
24 Feet
Engine
Horsepower
.5 hp
Overview
Weight
42 Pounds
Consumer Warranty
3 Years
Product Length
10.7 Inches
Product Width
8.4 Inches
Product Height
13.25 Inches
Style
Sewage Pumps
GPH
9600
Gallons
Switch Type
Vertical Float Switch
Style
Sewage Pump
GPH
9600 Gallons
Switch Type
Vertical
Features
Features
  • Automatic Submersible Cast Iron Sewage Pump
  • A workhorse for residential & light commercial sewage apps.
  • Heavy-Duty Epoxy Powder Coated Cast Iron Construction
  • Designed to provide years of reliable performance
  • Pump-Mounted Vertical Float Switch
  • Provides automatic or manual operation via piggyback plug
  • Rugged & Thermally Protected 1/2 HP Motor
  • Hermetically sealed, permanently lubricated design
  • Engineered 2-Vane Semi-Open HYTREL Polymer Impeller
  • Corrosion-resistant design, passes spherical solids up to 2"
  • High Capacity 2" Discharge
  • Will replace most sewage pumps without any plumbing changes
  • Quick-Disconnect 10' Power Cord
  • Allows for easy replacement of cord without breaking motor seals
  • Stainless Steel Rotor Shaft w/ Unitized Ceramic Carbon Seal
  • With permanently lubricated bearings for extended pump life
  • Non-Corrosive Stainless Steel & Brass Fasteners
  • Increases the lifespan of the pump even in the harshest systems
  • 3-Year Limited Warranty
Specifications
Base
Min Sump Basin Size
14 Inch
Motor
Voltage
120 Volt
Running Amps
12
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Starting Amps
22.5
Pump
Housing Material
Cast Iron
Solids Handling Size
2 inch
Float Type
Vertical Float
GPH @ 0 feet
9600
GPH @ 5 feet
8400
GPH @ 10 feet
6720
GPH @ 15 feet
5400
GPH @ 20 feet
3300
Discharge Port Size
2 Inch
Built-in check Valve
No
Manual Override
Yes
Max Head
24 Feet
Engine
Horsepower
.5 hp
Overview
Weight
42 Pounds
Consumer Warranty
3 Years
Product Length
10.7 Inches
Product Width
8.4 Inches
Product Height
13.25 Inches
Product Specs
+
Specifications
Base
Min Sump Basin Size
14 Inch
Motor
Voltage
120 Volt
Running Amps
12
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Starting Amps
22.5
Pump
Housing Material
Cast Iron
Solids Handling Size
2 inch
Float Type
Vertical Float
GPH @ 0 feet
9600
GPH @ 5 feet
8400
GPH @ 10 feet
6720
GPH @ 15 feet
5400
GPH @ 20 feet
3300
Discharge Port Size
2 Inch
Built-in check Valve
No
Manual Override
Yes
Max Head
24 Feet
Engine
Horsepower
.5 hp
Overview
Weight
42 Pounds
Consumer Warranty
3 Years
Product Length
10.7 Inches
Product Width
8.4 Inches
Product Height
13.25 Inches
