Liberty Pumps LSG203M - 2 HP Omnivore® Grinder Pump (208/230V 3-Phase) w/ 25' cord

Liberty Pumps LSG203M - 2 HP Omnivore® Grinder Pump (208/230V 3-Phase) w/ 25' cord
Model: LSG203M
$1,407.70
Ships in 7-14 Business Days
Free Shipping
Ships in 7-14 Business Days
Free Freight
Free Freight
*We currently CANNOT ship this product to Canada or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Style
Sewage Pumps
GPH
3000
Gallons
Switch Type
None
Style
Sewage Pump
GPH
3000 Gallons
Switch Type
None


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • Submersible Cast Iron Omnivore® Grinder Pump (Up to 100' Lift)
  • For residential/commercial systems w/ high solid content
  • Requires control box or float switch for automatic operation
  • Uni-Body Epoxy Powder Coated Cast Iron Construction
  • Designed to provide years of reliable performance
  • Hevy Duty 2 HP (208-230V 3-Phase) Motor
  • Hermetically sealed, permanently lubricated design
  • V-Slice® Cutter Technology (440 Stainless Steel)
  • Provides improved shredding performance over radial cutters
  • Back Vanes On Impeller & Spiraled Bottom Plate
  • Clog-free volute design provides superior solids clearing
  • Stainless Steel Rotor Shaft w/ Dual Seals
  • Carbon ceramic & Viton® double-lip lower seal for extended life
  • Non-Corrosive Stainless Steel Impeller, Fasteners & Clasp
  • Increases the lifespan of the pump even in the harshest systems
  • Minimizes lifting chain problems over the lifespan of the pump
  • Quick-Disconnect 25' Power Cord w/ 6-20P Plug (208/230V)
  • Requires a minimum 30-amp breaker for pump circuit
  • 3-Year Limited Warranty
  • (G90) Flange May Be Requried For Installation (Not Included)
Specifications
Base
Min Sump Basin Size
18 Inch
Motor
Running Amps
13.2
Thermal Protection
No
Power Cord Length
25 Feet
Oil Free Motor
No
Pump
Housing Material
Cast Iron
Solids Handling Size
2 inch
Float Type
No Switch
GPH @ 0 feet
3000
GPH @ 5 feet
3000
GPH @ 10 feet
3000
GPH @ 15 feet
3000
GPH @ 20 feet
3000
Discharge Port Size
1-1/4 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
2 hp
Overview
Made in USA
Yes
Weight
89 Pounds
Product Width
9.5 Inches
Product Height
19.5 Inches
Consumer Warranty
3 Years
UPC
671812113068
Style
Sewage Pumps
GPH
3000
Gallons
Switch Type
None
Style
Sewage Pump
GPH
3000 Gallons
Switch Type
None


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • Submersible Cast Iron Omnivore® Grinder Pump (Up to 100' Lift)
  • For residential/commercial systems w/ high solid content
  • Requires control box or float switch for automatic operation
  • Uni-Body Epoxy Powder Coated Cast Iron Construction
  • Designed to provide years of reliable performance
  • Hevy Duty 2 HP (208-230V 3-Phase) Motor
  • Hermetically sealed, permanently lubricated design
  • V-Slice® Cutter Technology (440 Stainless Steel)
  • Provides improved shredding performance over radial cutters
  • Back Vanes On Impeller & Spiraled Bottom Plate
  • Clog-free volute design provides superior solids clearing
  • Stainless Steel Rotor Shaft w/ Dual Seals
  • Carbon ceramic & Viton® double-lip lower seal for extended life
  • Non-Corrosive Stainless Steel Impeller, Fasteners & Clasp
  • Increases the lifespan of the pump even in the harshest systems
  • Minimizes lifting chain problems over the lifespan of the pump
  • Quick-Disconnect 25' Power Cord w/ 6-20P Plug (208/230V)
  • Requires a minimum 30-amp breaker for pump circuit
  • 3-Year Limited Warranty
  • (G90) Flange May Be Requried For Installation (Not Included)
Specifications
Base
Min Sump Basin Size
18 Inch
Motor
Running Amps
13.2
Thermal Protection
No
Power Cord Length
25 Feet
Oil Free Motor
No
Pump
Housing Material
Cast Iron
Solids Handling Size
2 inch
Float Type
No Switch
GPH @ 0 feet
3000
GPH @ 5 feet
3000
GPH @ 10 feet
3000
GPH @ 15 feet
3000
GPH @ 20 feet
3000
Discharge Port Size
1-1/4 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
2 hp
Overview
Made in USA
Yes
Weight
89 Pounds
Product Width
9.5 Inches
Product Height
19.5 Inches
Consumer Warranty
3 Years
UPC
671812113068
Product Specs
+
Specifications
Base
Min Sump Basin Size
18 Inch
Motor
Running Amps
13.2
Thermal Protection
No
Power Cord Length
25 Feet
Oil Free Motor
No
Pump
Housing Material
Cast Iron
Solids Handling Size
2 inch
Float Type
No Switch
GPH @ 0 feet
3000
GPH @ 5 feet
3000
GPH @ 10 feet
3000
GPH @ 15 feet
3000
GPH @ 20 feet
3000
Discharge Port Size
1-1/4 Inch
Built-in check Valve
No
Manual Override
Yes
Engine
Horsepower
2 hp
Overview
Made in USA
Yes
Weight
89 Pounds
Product Width
9.5 Inches
Product Height
19.5 Inches
Consumer Warranty
3 Years
UPC
671812113068
