Little Giant ES33D1-10 - 1/3 HP Cast Iron Submersible Sump Pump w/ Diaphragm Switch

Model:

506420

Write A Review
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Little Giant ES33D1-10 - 1/3 HP Cast Iron Submersible Sump Pump w/ Diaphragm Switch
Little Giant ES33D1-10 - 1/3 HP Cast Iron Submersible Sump Pump w/ Diaphragm Switch
Model: 506420
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Similar Products

Recommended Accessories

Sump Pumps Direct expert image
Expert Recommended Accessories Selected by Jim, our Expert
Optional Accessories 9
$524.00
Factory-Direct
$518.00
Factory-Direct
$99.99
In-Stock
$33.99
In-Stock
$34.50
In-Stock

Features

Style

Primary

GPH

3120 Gallons

Switch Type

Diaphragm

  • Contractor Grade, High Performance, Submersible Sump Pump
  • For use in residential and light commercial applications
  • Epoxy Coated Cast Iron Housing
  • Corrosion resistance design extends the life of the pump
  • Piggyback Diaphragm Pressure Switch
  • Provides reliable automatic operation
  • Thermal Overload Protected, Powerful 1/3 HP (5-Amp) PCS Motor
  • For high starting & running torque
  • Low amp draw to conserve electrical energy
  • Oil-Filled Motor Housing
  • For lifetime bearing lubrication & maximum heat dissipation
  • Recessed, Composite Vortex Impeller
  • Reduces clogging with the ability to pass up to 3/8" solids
  • Stainless Steel Fasteners
  • Protects against corrosion in harsh sump pits
  • Upper Sintered-Sleeve Bearing & Lower Ball Bearings
  • Minimizes friction while providing smooth & quiet operation
  • Carbon/Ceramic Mechanical Seal
  • Assure maximum protection against pump failure
  • 1-Year Limited Warranty
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov

Specifications

506420
specs product image PID-10256
Base
Min Sump Basin Size
18 Inch
Motor
Voltage
120 Volt
Thermal Protection
Yes
Power Cord Length
10 Feet
Oil Free Motor
No
Pump
Housing Material
Cast Iron
Solids Handling Size
.375 inch
Float Type
Diaphragm
GPH @ 0 feet
3120
GPH @ 5 feet
3120
GPH @ 10 feet
2400
GPH @ 15 feet
1680
Discharge Port Size
1-1/2 Inch
Check Valve Included
No
Float On
10-12 Inches
Float Off
4-6 Inches
Manual Override
Yes
Engine
Horsepower
.33 HP
Overview
Weight
28 Pounds
Consumer Warranty
1 Year
Product Length
9.75 Inches
Product Width
11.75 Inches
Product Height
9.25 Inches
UPC
010121109049
